20-30 Place Welded Canoe Trailer
Product Description
To calculate shipping rate click here!
Introducing the Tough Weld 20-30 place canoe trailer. This trailer is designed to transport and/or store canoes upside down so as not to fill with water. It will hold 20-30 canoes depending on length of canoes and how you layer them. If shorter canoes, you can feather them across the arms to hold up to thirty canoes. With longer, wider canoes, this may not be possible. There is 18" up and down clearance in each opening. The storage arms are 36" long each. The storage trees are 6' apart per section and 8' apart between the two sections. The all-welded construction design allows this trailer to hold up to the rigors of climbing, loading and unloading in a rental setting. Competitor's bolt-together design is just a lot of bolts to police and make sure no bolts get loose and create a dangerous situation. The main-frame is 6" C channel, the tongue is 4" tube and cross arms are 2" tube. This trailer can be ordered in painted steel, hot-dipped galvanized or aluminum. These are built-to-order in Georgia and come fully assembled. There is an optional fiberglass 8' oar storage box available that fits in the opening of storage rack. The axle on this trailer is adjustable, so you can reposition it if there is too much tongue weight. To balance the weight over the axle, start loading the trailer from the bottom of the rack.
Trailer Specifications
Introducing the Tough Weld 20-30 place canoe trailer. This trailer is designed to transport and/or store canoes upside down so as not to fill with water. It will hold 20-30 canoes depending on length of canoes and how you layer them. If shorter canoes, you can feather them across the arms to hold up to thirty canoes. With longer, wider canoes, this may not be possible. There is 18" up and down clearance in each opening. The storage arms are 36" long each. The storage trees are 6' apart per section and 8' apart between the two sections. The all-welded construction design allows this trailer to hold up to the rigors of climbing, loading and unloading in a rental setting. Competitor's bolt-together design is just a lot of bolts to police and make sure no bolts get loose and create a dangerous situation. The main-frame is 6" C channel, the tongue is 4" tube and cross arms are 2" tube. This trailer can be ordered in painted steel, hot-dipped galvanized or aluminum. These are built-to-order in Georgia and come fully assembled. There is an optional fiberglass 8' oar storage box available that fits in the opening of storage rack. The axle on this trailer is adjustable, so you can reposition it if there is too much tongue weight. To balance the weight over the axle, start loading the trailer from the bottom of the rack.
| Specification | Details |
|---|---|
| Assembly | Fully Assembled |
| Length | 27'7" |
| Width | 8' |
| Height | 10' |
| Axle Type | Tandem Axles |
| Tire Size | 13" |
| Weight Capacity | 4000 lbs. |
| Trailer Weight | ~1450 lbs. |
| Tongue Weight | Adjustable |
| Ball Size | 2" |
| Material | Hot Dipped Galvanized Steel |
| Brand | Toughweld |
