Tohatsu 6HP Tiller 4-Stroke Outboard
Product Description
| Engine Type | 4-Stroke 1 Cylinder |
| Output | 6 hp (4.4 kw) |
| Displacement | 123 cc (7.5 cu.in.) |
| Bore x Stroke | 59 x 45 mm (2.32 x 1.77 in) |
| Max. RPM Range | 5,000 - 6,000 |
| Starting System | Manual |
| Control Type | Tiller Handle |
| Gear Shift | Forward - Neutral |
| Dry Weight | 57 lbs. (26 kg) |
| Fuel Tank | Internal Fuel Tank Models (MFS6DD) : 0.3 US Gal. (1.15 Lit) Integral Tank (Includes an External Fuel Tank Connector installed on engine to allow user to use an optional external fuel tank) External Fuel Tank Models (MFS6D) : 3.1 US Gal. (12 Lit) Separate Fuel Tank |
| Oil Capacity | 15 fl oz (450 mL) |
| Oil Type | NMMA Certified FC-W® 4-stroke oil** SAE 10W-30/40 (SF, SG, SH, SJ) |
| Gear Ratio | 2.15:1 |
| Propeller | Aluminum (Standard) |
| Propeller Selection Range | 6" - 9" |
- ✓ 360° Full Pivot Steering
- ✓ Newly designed Tohatsu’s unique front and back carrying handles for easier transportation
- ✓ 4-Point Vibration Dampening
- ✓ Easy Check Oil Gauge
- ✓ Digital CD ignition for easier engine starting, quicker throttle response and smoother trolling
- ✓ Thermostat Controlled Cooling System
- ✓ Recoil starter with larger reel making manual starting fast and easy
- ✓ Shallow water drive
- ✓ 6 trim positions
- ✓ Ultra-low emission, EPA and CARB 3-Star rating approved
- ✓ Newly designed top and bottom cowls based on Tohatsu Design Philosophy for Marine Products
- ✓ 3-way storage positions without worrying about oil spill
- ✓ Light and compact
- ✓ Front mounted shift lever, an industry first in its class
- ✓ Greatly reduced vibration for smooth and stable running at all speeds
- ✓ Greatly reduced induction noise for a quieter ride
- ✓ 5 Year limited warranty
| Transom Height | 15" (Short) / 20" (Long) / 25" Extra Long |
| Width | 12.6" |
| Length with handle | 32.4"" |
